Aegis Grounding Ring Chart

The clamp on design is an easy tap and drill installation for external motor end bracket installations.

Aegis grounding ring chart. Great for field retrofits. Use 2 to 4 clamps depending on the style of the motor end bracket. See note in red below. Parts list metric aegis sgr solid split ring.

If yes and you want to mount the ring to fit the shaft shoulder then you need to measure the length of the shoulder. Shaft grounding rings sgr for low voltage motors up to 500hp. The aegis ring is designed to be a wear to fit device. 31 winterbrook road mechanic falls me 04256 iso 9001 2015 certified phone.

8 the aegis grounding ring is a zero maintenance product. The aegis shaft grounding technology prevents bearing fluting damage when motors are controlled by variable frequency drives vfd. Various mounting options are listed below. Using proprietary electron transport technology the conductive microfibers inside the aegis ring provide the most reliable current diversion technology for shaft grounding with a path of least resistance to dramatically extend motor life.

Aegis shaft grounding ring technology is the only technology that combines both contact and non contact nanogap technology to reliably protect bearings from electrical discharges that cause pitting frosting and flutingdamage. 1 207 998 5140 toll free u s. Find a local distributor in your country or region. After 200k hours it may wear to exactly fit the motor s shaft but it will continue to operate.

The aegis shaft grounding ring prevents electrical bearing fluting damage by safely diverting harmful shaft voltages and bearing currents to ground. What is the life cycle. The new aegis shaft grounding ring kit with universal mounting brackets allows universal mounting options to fit almost any motor design in nema frames from 56 to 449t and iec frames from 132m to 355m. Because aegis rings operate with virtually zero friction the fibers wear very slowly if at all.

Used to install the aegis ring without drilling and tapping into motor bracket. Aegis sgr bearing protection rings are designed to divert bearing currents to ground by providing a highly reliable shaft grounding path. 31 winterbrook road mechanic falls me 04256 iso 9001 2015 certified phone. 1 207 998 5140 toll free u s.

Request live aegis training. Aegis ring technology uses proprietary conductive micro fibersarranged circumferentially around the motor shaft and secured in our patented aegis fiberlock. Overview selection guide. Shaft grounding rings sgr for low voltage motors up to 500hp.

Aegis ipro current capability chart 0 50 100 150 200 250 2 50mm 4 100mm 8 200mm 16 400mm 32 800mm aegis ipro grounding ring high frequency current discharge capability amps at 50 watts. If still applicable measure shaft shoulder diameter then refer to parts list as shown above to locate the correct sgr part number.
