Aiphone door station mounting height. Controls for your aiphone would need to be no higher than 48 and no lower than 15 for a forward or side approach that is unobstructed. The exception of course is when a door station is being installed on a vehicle entrance or an entrance used by disabled people in wheel chairs. Tall viewing height. 1 500 mm 5 ix ba.

Verify up is facing up drain holes low voltage cable 1 gang box mounting height box center ix da. 52 5mm 2 1 16 or more special screwdriver included tighten loosen recommended mounting height center of gang box 1 350 mm 4 5 max 1 900 6 2 2 3 how to connect connection precautions cat 5e 6 cable. Also objects projecting from walls with their leading edges between 27 in and 80 in above the finished floor should not protrude more than 4 in. A common mistake is to install door stations at the wrong height.

425 455 0510 toll free. The illustrations used in this manual may differ from the actual stations. Jk da intercom system pdf manual download. Form c dry contact for door release 24v ac dc 500ma indoor or outdoor use.

Contact technical support. Video door station flush mount guidance enabled type video door station ps 2420s ps 2420ul 24v dc power supply jpw ba long distance adaptor jp 8z distribution adaptor power supply other door station adaptor gt d audio only door station ier 2 call extension speaker ry 3dl multiple door release adaptor ac 10s access control keypad surface mount jp dv ac 10s 13. 1 300 mm 4 3 included screws x2 45 23 4 open the terminal cover and connect the. Connects using cat 5e or cat 6 wire.

1 4 cmos view area. Contact us phone numbers. Video door stations should be installed at 1500mm above finished floor level. From decades of providing technical support for aiphone we find the problem is rarely equipment related.

Audio door stations should be installed at this height if possible. Installation of door station mounting frame attach the main unit to the mounting frame and put the panel on. It s free easy to use and always accurate. Cat 5e 6 cable low voltage lines special screws included 4 inlet 2 gang box unit depth.

Video door station surface mount. When a communication system is required for this one of the main ada requirements is how it is positioned regarding its height. Attach the door station. Features digital ptz video camera.

View and download aiphone jk da installation manual online. Master station with the customer. In this case the door station can. Attach the mounting frame do not obstruct.

Perform installation and connection only after gaining sufficient understanding of the system and this manual.
